Description
xNANO RTK Receiver Pro
The NANO RTK Receiver Pro is a cutting-edge, high-precision RTK navigation module powered by a next-generation GNSS SoC. It supports simultaneous multi-constellation tracking of all visible satellite systems including GPS, QZSS, BDS, GALILEO, GLONASS, and IRNSS. Engineered for seamless field operations, it features built-in Bluetooth connectivity, allowing full compatibility with both Android and iOS devices for wireless NMEA data streaming and configuration.
The receiver dynamically scales across versatile applications, offering full Base and Rover deployment modes, and supports flexible high-precision helical or patch patch antennas.
NANO RTK Receiver supports the following GIS mobile app and others app with BLE or TCP connections:
- SW Maps
- QField
- ROLAVICam
Key Features
- Comprehensive multi-constellation tracking: GPS, QZSS, BDS, GALILEO, GLONASS, and IRNSS.
- Full operational adaptability: Configurable as either a high-precision Base or Rover station.
- Wireless field interoperability: Seamless Bluetooth pairing with Android and iPhone/iPad devices.
- Flexible connectivity interfaces: Supports both Type-C USB and a 6-Pin 1.25mm pitch connector.
- Autopilot readiness: Fully compatible with Ardupilot and PX4 open-source platforms.
Ordering Information
Part Number (SKU)Configuration
NANO-DG-95-15RTK receiver, L1/L5 Bands, Type-C & 6P Connectors
NANO-RTK-15-H01RTK receiver, Helix Antenna, L1/L5 Bands, Type-C & 6P Connectors
Technical Specifications
Hardware Channels 128 Channels
Tracking Frequencies GPS/QZSS: L1, L5/L2
BDS: B1, B2a/B2I
GALILEO: E1, E5a/E5b
GLONASS: L1, L2
IRNSS: L5
BDS: B1, B2a/B2I
GALILEO: E1, E5a/E5b
GLONASS: L1, L2
IRNSS: L5
Hardware Interfaces USB Type-C (Default: 230400 bps)
6-Pin 1.25mm Pitch Connector
2 x UART Ports
6-Pin 1.25mm Pitch Connector
2 x UART Ports
Positioning Performance Horizontal Accuracy: 10mm + 1 PPM
Vertical Accuracy: 30mm + 1 PPM
RTK Initialization: < 10 seconds
Data Update Rate: 1 / 5 Hz
Vertical Accuracy: 30mm + 1 PPM
RTK Initialization: < 10 seconds
Data Update Rate: 1 / 5 Hz
Antenna Connection Port SMA Connector
Power Input / Current Draw 4.75 〜 5.25 V / ~200 mA
Physical Dimensions 65 mm × 36 mm
Net Weight 10 g
Package List
- 1 x NANO RTK Receiver Pro
- 1 x USB Type-C Cable (1m)
- 1 x 6P GH-1.25 GH-1.25 Cable (20cm)
